  5. Rhino Solar 3HP IGBT base AC & DC VFD Designed & Manufactured in India

Rhino Solar 3HP IGBT base AC & DC VFD Designed & Manufactured in India

Model: RMCS-2314
Availability : Out of Stock
₹6,500.00
Current Reviews: 0 Add Your Review
GST Input Tax Credit @ 5 % of ₹325 available. (Know More)
Warranty : 1 Year
Free Economy Shipping option available
 Sold Out

The RHINO SOLAR PUMP VFD is Designed to Deliver Water in Remote Locations Where Access to Reliable AC Power May Be Uncertain or Non-existent Also It is Suitable for All the Locations. This Controller Operates Seamlessly on DC and AC Power both. This Series of AC and DC Motor Drive with abundant features, Including multi-function I/O terminal, V/f control and auto-torque/auto-slip compensation, built-in digital keypad that can be connected to VFD with extended wire. During Sunny Days, the Solar Pumping System can Consistently and Efficiently Move Water. In Instances Where There Are No Batteries or Other Energy Storage Devices, It is Advisable to Pump Water to a Reservoir for Future Use. Water Sources can Range from Natural Bodies Like Rivers, Lakes, and Wells to Specialized Waterways.

To Manage the Pump's Operation Effectively, a Float Switch can Be Installed in the Water Tower. This Three Phase Solar Pump Drive Continuously Monitors System Performance and Detects a Variety of Abnormal Conditions. In Many Cases, the Controller Will Compensate as Needed to Maintain Continuous System Operation. However, if There is a High Risk of Equipment Damage, the Controller Will Protect the System and Display the Fault Condition. The Solar Pump Controller is a Variable Speed Motor Drive Designed to Operate Various AC Induction Pump Sets (and BLDC will suggest) Specifically Engineered for 3HP Pumps.
Solar VFD Features:
  • classification according to IP : IP65
  • It operates on 3 Phase AC Induction Motor, using the V/F (Voltage/Frequency) Method.
  • It can accept DC power ranging from 60(Vdc) to 450(Vdc), and for AC power, it directly takes 220(Vac).
  • Continuous and Highly Efficient Power Tracking at 99%
  • Ideal for 1HP to 3HP AC Induction Motor and BLDC Motor For DC.
  • Rated to Handle up to 2.2kw Input DC Power with 13amps of Continuous Input Current.
  • Operating Flawlessly within an Ambient Temperature Range of 0 to 89 Degrees Celsius.
  • Switch is given on the back to turn on and off the AC supply.
  • This System Prioritizes Safety with Built-in Features Such as Reverse Polarity Protection, Over-Temperature Safeguards, Under-Voltage Protection, and Overload Protection.
  • Float Sensor Inputs can be Connector to Control the Water Level in a fixed Tank System. In case a Float Sensor is not intended to be used Please Hook up a Short Circuit Wire between 0V / Reference and TL Input.


Power Terminals:
   Terminal Name    Description
P+ Positive DC Input from Panel (MC4 Connector)
P- Negative DC Input from Panel (MC4 Connector)
AC Input P (Brown)
AC Input N (Black)
AC Earthing (Green)

Motor Terminals:
   Terminal Name    Description
U Motor Phase 1 (Red)
V Motor Phase 2 (Yellow)
W Motor Phase 3 (Blue)

   Terminal No.    Terminal Name
TH Tank High Input (Red)
TL Tank Low Float Sensor Input (Green)
GND Reference Voltage for Float Sensor (Black)

Display and Buttons:
   Button Name    Function
Set Saves the Parameters to Memory
Enter Moves to the Next Parameter
Up Increases the Parameter Value
Down Decreases the Parameter Value
Switch

Changes the LED Segment Display

Parameters as per the above
   ON/OFF    To turn ON or turn Off the inverter

General Parameters:
 Parameter  Name Description  Default Value
P2 NO LOAD FREQUENCY The Frequency at No-Load error 40
P5 MOTOR PEAK CURRENT LIMIT Sets the Peak Current for Motor Coil 310
P7 PI LOOP OVERALL GAIN Peak Gain Setting for the PI loop 515
P10 V/F MOTOR RATED VOLTAGE The voltage at the rated frequency 80
P11 V/F MOTOR RATED FREQUENCY The rated frequency of the motor 50

ERROR Codes Description:
ERROR on Display NAME DESCRIPTION
ERROR_STATE_NOERROR    Motor is Off, Not Error
ERROR_STATE_LOWPWR Inverter Auto Shut due to low input power
ERROR_STATE_LOWVLT Inverter Auto Shut due to low input voltage
ERROR_STATE_MTRJAM V/F Ratio Incorret
ERROR_STATE_CFAULT Inverter Circuit Failure due to High Current
ERROR_STATE_VFAULT Inverter Circuit Failure due to High Voltage
ERROR_STATE_NOLOAD Motor Not drawing sufficient Power
ERROR_STATE_OVHEAT Inverter Auto Shut due to Over Temperature
ERROR_STATE_LOWSTR Inverter Auto Shut due to low start-up power
ERROR_STATE_PHASE Incorrect Motor Connection not proper or wire loose

System Diagnostics:
The solar pump controller continuously monitors system performance and detects a variety of abnormal conditions. In many cases, the controller will compensate as needed to maintain continuous system operation; however, if there is high risk of equipment damage, the controller will protect the system and display the fault condition. If possible, the controller will try to restart itself when the fault condition subsides. See Diagnostics and Troubleshooting section for a list of Fault Codes and corrective actions.

Motor Soft-Start Normally:
When there is a demand for water and power is available, the solar pump controller will be operating. Whenever the solar pump controller detects a need for water, the controller always “ramps up” the motor speed while gradually increasing motor voltage, resulting in a cooler motor and lower start-up current compared to conventional water systems. Due to the controller’s soft-start feature this will not harm the motor. It will help to extend the motor lifetime.

Over Temperature Fold back:
The solar pump controller is designed for full power operation from a solar array in ambient temperatures up to 90°C. In excess of 90°C temperature conditions, the controller will switch off the output.
