Get high class my1016zL 24v 350w electric wheelchair pmdc motor for your electric bike to build your known e-bike, this motor is one of the most important parts of your electric bike. E-bikes generally combine both pedal-assist sensors as well as a throttle. some electric bikes have an electric motor that operates on a power-on-demand basis only. in this case, the electric motor is engaged and operated manually using a throttle, which is usually on the hand grip just like the ones on a motorbike or scooter.

This my1016zL is a very popular high torque reduction motor and extremely reliable with its power requirements. it is the most commonly used motor for scooters, bikes, and wheelchair! this motor is capable of rotation in both, the clockwise or counterclockwise direction by reversing the motor’s power wires.

Features:

• With small size
• low speed high torque output
• low noise
• high reliability
• easy maintenance

Specifications:

• Working Voltage : 24V
• lRated Power : 350W
• Shaft Type : Key shaft
• Rated Speed : 120RPM
• Rated Torque : 20N.m
• Based motor RPM : 3700RPM
• Rated Current : 18.7A
• Insulation class : E
• Shaft Diameter : 17mm
• Shaft Length : 46mm
• Insulation Class : E
• Protect Grade : IP33
• Weight : 3.77 kg

Package Includes:

• 1 x MY1016ZL 24V 350W DC Motor
