Holybro M9N UART GPS Compatible with Hex Pixhawk Cube

Model: RKI-5053
Availability : In Stock
₹5,432.00
Current Reviews: 0 Add Your Review
GST Input Tax Credit @ 18 % of ₹977.76 available. (Know More)
Warranty : None
Free Economy Shipping option available
QTY :

The M9N GPS has an UBLOX M9N module, IST8310 compass, tri-colored LED indicator, and a safety switch. There are 3 different connectors options for different purposes.

This module available with a baud rate of 115200 (38400 previously).
Features
  • Ublox Neo-M9N module
  • Industry leading –167 dBm navigation sensitivity
  • Cold starts: 26s
  • LNA MAX2659ELT+
  • 25 x 25 x 4 mm ceramic patch antenna
  • Rechargeable Farah capacitance
  • Low noise 3.3V regulator
  • Current consumption: less than 150mA @ 5V
  • Fix indicator LEDs
  • Protective case
  • Cable Length: 26cm (Approx.)
  • Diameter 50mm total size, 32 grams with case (Approx.)
Setup with Pixhawk Cube or compatible autopilot
  • Connect to GPS port / Telemetry serial port with 6 pin connector
  • Disable all other GPS by setting SERIALX_PROTOCOL TO -1
  • For example if connected to pixhawk cube on GPS 2 port, set SERIAL3_PROTOCOL TO -1 to disable GPS on GPS1 port. If you are using port for something else set it to any other value than 5.
Package Includes:
  • 1 x M9N GPS
  • 1 x ‘X’ type folding pedestal mount
  • 1 x Carbon rod 70mm & 140mm
