Ideal Motor for CNC machines and other machinery. Standard NEMA 34 frame size. 45Kgcm bipolar configuration motor. Works well with RMCS-1101 Stepper Drive at 4.2Amp configuration.

Features

• Step Angle : 1.8 Degree
• Configuration: 4 wire bipolar stepper motor
• Holding Torque: 45kgcm bipolar mode
• Phase current : 4Amp
• Resistance/phase: 0.87ohm
• Inductance/Phase : 7.3mH
• Rotor inertia: 1400 gcm²
• Length (L): 80mm
• Shaft Dia : 12.70mm
• Shaft Length : 32mm
• Weight: 2300 grams

Wiring Details:

• A+ = Green

• A-  = Yellow

• B+ = Red

• B-  = White

Mechanical Drawing

Datasheet
