RPLIDAR A3 360° Laser Range Scanner 25m

Model: RKI-4864
Availability : In Stock
₹56,600.00  ₹46,000.00
Sale
-19%
Current Reviews: 0 Add Your Review
GST Input Tax Credit @ 18 % of ₹8280 available. (Know More)
Warranty : None
Free Economy Shipping option available
QTY :

The RPLIDAR A3 is the next generation low cost 360 degree 2D laser scanner (LIDAR) solution developed by SLAMTEC. It can take up to 16000 samples of laser ranging per second with high rotation speed. And equipped with SLAMTEC patented OPTMAG technology, it breakouts the life limitation of traditional LIDAR system so as to work stably for a long time.

The system can perform 2D 360-degree scan within a 25-meter range. The generated 2D point cloud data can be used in mapping, localization and object/environment modeling.

Compared with RPLIDARs in other series, RPLIDAR A3M1 has a more stable performance when detecting objects in long distance, objects in white or black alternatively and objects under direct sunlight, which is ideal for map building in the outdoor environment within a 25-meter ranging radius.
Specifications:
  • RPLIDRA A3M1 supports to work under two modes alternatively: enhanced mode and outdoor mode.

  Enhanced Mode Outdoor Mode
Application Extreme performance Ideal for indoor environments with maximum ranging distance and sampling frequency. Extreme reliability Ideal for both outdoor and indoor environments with reliable resistance to daylight.
White object Distance Range White object: 25 meters White object: 20 meters
Dark object Distance Range Dark object: 10 meters Dark object: TBD
Sample Rate 16000 times per second 10000 times per second
Scan Rate Typical value: 15 HZ (adjustable between 10 HZ-20 HZ) Typical value: 15 HZ (adjustable between 10 HZ-20 HZ)
Angular Resolution 0.3375° 0.54°
Communication Interface TTL UART TTL UART
Communication Speed 256000bps 256000bps
Compatibility Support former SDK protocols Support former SDK protocols

Features:










Product Includes:
  • 1x RPLIDAR A3
  • 1x USB Adapter
  • 1x micro-USB Cable
  • 1x Power Adapter
