Nema34 STEPPER MOTOR WITH WORM GEARBOX 750kgcm

Model: RMCS-2028
Availability : In Stock
₹9,800.00
Current Reviews: 0 Add Your Review
GST Input Tax Credit @ 18 % of ₹1764 available. (Know More)
Warranty : 3 Month
Free Economy Shipping option available
QTY :

Ideal stepper Motor for CNC machines, diamond machines, laser machines. Standard NEMA34 frame size with 750Kgcm holding torque.

Worm reducer gearbox with a 1:15 gear ratio at rated torque of 750Kgcm.
Features:
  • Holding Torque: 750KG-cm

Motor Specifications:
  • Step Angle : 1.8 Degree
  • Configuration: 4 wire bipolar stepper motor
  • Holding Torque: 85kgcm bipolar mode
  • Phase current : 5Amp
  • Resistance/phase: 0.76ohm
  • Inductance/Phase : 8.5mH
  • Rotor inertia: 2700 gcm2
  • Length (L): 118mm
  • Shaft Dia : 12.7mm
  • Shaft Length : 32mm
  • Weight: 3800 grams

Gearbox Specifications:
  • Installations for gear : Horizontal
  • Gear Ratio : 15 : 1
  • Output Key Shaft Diameter : 20.8mm
  • Output Shaft Diameter : 14 mm
  • Ouput Key Diameter: 6mm
  • Input Key Diameter: 5mm
  • Category : Worm gear reducer
  • Gearbox weight : 2.03kg

Package Includes:
  • 1 x NEMA34 STEPPER MOTOR WITH WORM GEARBOX 750KGCM
