Nema23 STEPPER MOTOR WITH worm GEARBOX 70Kgcm

Model: RMCS-2060
Availability : In Stock
₹5,200.00  ₹5,308.00
Sale
--2%
Current Reviews: 0 Add Your Review
GST Input Tax Credit @ 18 % of ₹955.44 available. (Know More)
Warranty : 3 Month
Free Economy Shipping option available
DRIVE
Power Supply
QTY :

Ideal stepper Motor for CNC machines, diamond machines, laser machines. Standard NEMA23 frame size with 70Kgcm holding torque.

Worm reducer gearbox with a 1:5 gear ratio at rated torque of 70Kgcm.
Features:
  • Holding Torque: 70KG-cm

Motor Specifications:
  • Step Angle : 1.8 Degree, 50 pole
  • Configuration: 4 wire bipolar stepper motor
  • Rated Voltage: 3.2V
  • Phase current: 4Amp
  • Resistance/phase: 0.35ohm
  • Inductance/Phase: 1.8mH
  • Rotor inertia: 480gcm2
  • Insulation Class: Class B
  • Length (L): 102mm
  • Shaft Dia : 8mm
  • Shaft Length : 20mm

Gearbox Specifications:
  • Installations for gera : Horizontal
  • Category : Worm gear reducer
  • Gearbox weight : 1.2kg
  • Motor With Gearbox weight : 2.6kg

Package Includes:
  • 1 x NEMA23 STEPPER MOTOR WITH WORM GEARBOX 70KGCM

Pm : 60mm
Bm : 5mm
Tm : 16.3mm
Dm : 14mm
