The Rhino MD13S 13Amp DC Motor Driver has great improvement in current protection, which the MD10C does not have. With a new circuit and design, MD13S is able to output current to 30A max. And the continuous current is at 13A (in room temperature of 25°C). Brush is the most used motor worldwide because of the ease of operation. Just supply two terminals of the brush motor with DC voltage, and it will start rotating! Yet, you need a good motor driver to control the speed and direction of a microcontroller.

Features

• Bi-directional control for 1 brushed DC motor.
• Support motor voltage ranges from  6V to 30V
• Maximum current up to 13A continuous and 30A peak (10 seconds).
• 3.3V and 5V logic level input.
• Solid state components provide faster response time and eliminate the wear and tear of a mechanical relay.
• Fully NMOS H-Bridge for better efficiency and no heat sink is required.
• Speed control PWM frequency up to 20KHz (Actual output frequency is the same as input frequency).
• Support both locked-antiphase and sign-magnitude PWM operation, NOT RC (Radio Control) PWM.



Specifications:

Driver Model	Rhino MD13S
Operating Voltage(VDC)	6 to 30
Peak Current (A)	28 (10 seconds)
Continuous Current (A)	13
No. of Channels	1
Operating Modes	PWM (Lock-Antiphase and Sign-Magnitude): Yes, UART: No, Analog:No, RC Servo Signal: No
LED Indicator	Yes
Test/Manual Button	Yes
Cooling Fan	No
Arduino Sheild	No- can be used with Wire connecon
Speed Control	Yes
Dimensions in mm (LxWxH)	62 x 33 x 12
Weight (gm)	103g
Others	No heat sink is required

• 1 x Rhino DC Motor Driver MD13S 13Amp
