An water cooled CNC spindle with excellent quality over surface finish, high acceleration capability, acquiring less installation space and easy commissioning.

VFD-M is a Sensor less Vector Micro AC Drive. The compact design is ideal for small and medium horsepower applications. The M drive is designed to provide an ultra-low-noise operation, and includes several innovative technologies that reduce interference.

VFD Specifications:

• Nominal Input VAC : 208,240 VAC
• Input Range VAC : 200 to 240 Volts AC
• HP (CT) : 2 Horsepower
• Amps (CT) : 7 Amps
• Input Phase : 1
• Operator Controls : Keypad Included
• Max. Frequency : 400 Hertz
• Braking Type : DC Injection; Dynamic Braking
• Motor Control-Max Level : Open Loop Vector (Sensor less Vector)
• Enclosure Rating : IP20
• Net Weight : 1.3 Kg
